1060 aluminum plate is suitable for CTP plate base 1050A

What is CTP plate?

The CTP plate in the printing industry refers to the printing plate making technology that directly transfers the numbers, pictures or pages edited in the electronic prepress processing system or color desktop system to the printing press without subsequent processing.

CTP plates are mostly used for high-end color printing plate making. To ensure the quality of the printing plate, the apparent quality of the plate base is a prerequisite. CTP plate base usually uses 1 series high-quality pure aluminum plate, such as 1050A aluminum plate, 1060 aluminum plate, 1050 aluminum plate, 1070 aluminum plate, etc.

Specifications of aluminum materials for CTP plate base:

Chemical composition of aluminum plate for CTP plate base:

Mechanical properties of 1050 aluminum sheet:

Tensile strength σb (MPa): 60～100

Elongation δ/（%)：≥23

Elongation 50mm/（%)：≥25

Mechanical properties of 1050A aluminum sheet:

Tensile strength σb (MPa): 60～95

Tensile strength σb (MPa):≥65

Conditional yield strength σ0.2 (MPa):≥20

1060 aluminum sheet mechanical properties:

Tensile strength σb (MPa): 110-136

Elongation δ10 (%): 3-5

1 series aluminum plate is suitable for CTP plate base features:

It has the advantages of high printing quality, strong printing resistance, environmental friendliness, cleanliness and sanitation, and reasonable cost.

1. High flatness: ensure the stability and consistency of printing quality

2. Environmental protection and cleanliness: aluminum plate does not contain harmful substances and is recyclable. The surface is smooth and not easy to be contaminated with dust and dirt

3. Low cost: 1 series aluminum plate has a single production process and a relatively low price

4. High hardness and strength: CTP plate base can withstand high-intensity printing force

5. Good hydrophilicity: good balance of water and ink

CTP plate has very high requirements for plate base quality:

CTP plate has high requirements for plate base flatness, and no unevenness is allowed, because most CTP equipment uses scanning imaging, unlike PS plate exposure, which uses vacuuming to make the plate surface and film close together. If the plate has poor flatness, it will affect the quality of laser imaging.
